XТZ-181.22

Tractor description

XTZ-181.22 is an upgraded version of the T-150-05-09 tractor, which, combined with a modified transmission, chassis (rubber track - 1 680 mm.,), control systems, ergonomic design and increased comfort for the operator allows the tractor to be used in modern Agricultural technologies with a higher driving force.
The undoubted advantage of the XTZ-181.22 crawler tractor is its low cost maintenance.
Use:
- agricultural operations: basic tillage, sowing;

Technical specifications

Engine
Engine model	YaMZ-238
Environmental class	0
Working volume, l.	14,86
Rated power, kW (hp)	140 (190)
Rated speed (rpm)	2100
Maximum torque Nm/rpm	883/1250-1450
Number of cylinders, pcs.	8
Fuel rate at rated engine power	227 (167)
Fuel system type	High pressure fuel pump
Chassis
Wheel formula	Tracked, with torsion-balanced suspension
Transmission	PowerShift 9/3
Maximum transport speed, km/h	16,40
Working speeds, km/h	I – (4,56-6,29) II– (7,20-9,94) III – (11,88-16,40)
Сaterpillar	Rubber track, 645 mm
Track gauge, mm.	1680
Turning radius, m.	2,75
Agrotechnical clearance	300
Hydraulic system
Type of hydraulic system	With one hydraulic pump and single hydraulic tank
Pump output (l/min)	130
Number of pairs of pins	4
Single Section Throughput hydrodistributor, l/min	0 - 100 mechanical adjustment of each section
Sections of work with hydraulic motors, pcs.	2
Maximum fluid flow for working with hydraulic motors, l/min	70
Hinged system
Type of attachment system	Articulated linkage with longitudinal links and hook grips
Sizes of connecting balls, mm	32 × 51 - upper link, 37 × 45 - lower link
Max. carrying capacity, kg	4200
PTO
PTO Type	independent. Single stage gearbox
PTO rotation speed, rpm	540 / 1000
Electrical system
Voltage	12
Starter voltage	24
Accumulator battery	6СТ-190А3, 2 pcs
Dimensions and weight
Length, width, height, mm.	5700, 2325, 3185
Operating weight (without ballast), kg	12120
Refueling capacities
Fuel tank, l	430
